完美接合3D打印件成大型製品


Preparing the Print 接合前準備

At first you have to prepare the surface for gluing. It has to be rough so as to increase the adhesion of the glue. Use 150 grit sandpaper. Next, clean this surface with a piece of cloth damped with petroleum ether off dust and oil. 首先,你必須準備好表面進行膠合。 它必須是粗糙的,以便增加膠的粘附。 使用150砂紙。 接下來,用一塊用石油醚除去灰塵和油的布擦淨表面。

gluing_1_1-825x550



Gluing the Print 膠合打印

  1. Cover the surface with glue. We recommend using cyanoacrylic glue for plastics. 用膠水覆蓋表面。 我們建議使用氰基丙烯酸膠為塑料。
  2. Spread the glue across the surface. 在表面塗抹膠水。
  3. Put the two parts together. 把兩個部分放在一起。
  4. Leave the print for the time required by the producer of the glue. To ensure proper bonding, use clamps which will keep the two parts as close to each other as possible. 留下印刷品所需的膠水的生產商的時間。 為了確保正確的粘接,使用夾具,這將保持兩個部分盡可能彼此靠近。

gluing_2_1-825x550 gluing_2_2-825x550 gluing_2_3a-825x550 gluing_2_3b-825x550 gluing_2_4b-825x550



Finishing off the 3D Print with a Grinder and Sandpaper 使用磨床和砂紙完成3D打印

If there are glue residues, remove them using a grinder or a piece of sandpaper. If it is possible, remove dried glue residues with a scalpel. 如果有殘膠,請使用研磨機或一塊砂紙清除。 如果可能,用手術刀清除乾膠殘餘物。

gluing_3_1b-825x550 gluing_3_1a-825x550
